ABB AC DRIVE ACS850 ACS850-04-035A-5+J40018.5KW 415V
ABB AC Drive ACS850-04-035A-5+J400
Power Rating: 18.5 kW Input Voltage: 415V, ±10%
Frequency: 50/60 Hz Output Voltage: 0 to Input Voltage
Output Current: 35 A
Control Modes:
– V/Hz (Volts per Hertz)
– Open-Loop Vector Control
– Closed-Loop Vector Control
Motor Control Features:
– Accurate Speed and Torque Control
– Adaptive Programming for Optimal Performance
– Overload Protection
– Stall Prevention
– Auto-Tuning for Motor Parameters
Communication Interfaces:
– Modbus RTU
– Modbus TCP/IP
– Embedded Ethernet
– I/O Expansion Slot for Communication Modules
User Interface:
– Keypad with LCD Display
– Real-Time Monitoring of Operating Parameters
– Intuitive Navigation for Configuration and Setup
Operating Temperature Range: -10°C to +50°C (14°F to 122°F)
Enclosure: IP21 (NEMA 1)
Cooling: Built-in Fan
Dimensions (H x W x D): 490 mm x 210 mm x 320 mm (19.3 in x 8.3 in x 12.6 in)
Weight: Approximately 17 kg (37.5 lbs)
Certifications:
– CE (European Conformity)
– UL (Underwriters Laboratories)
– RoHS (Restriction of Hazardous Substances)
Applications:
– Manufacturing Processes
– Material Handling Systems
– HVAC Systems
– Water Treatment Facilities
– Conveyor Systems
– Pumping Applications
Features:
– Energy-Saving Mode
– Built-in I/O for Enhanced Connectivity
– Programmable Logic Control (PLC) Capabilities
– Dynamic Braking Capability
– Built-in EMC (Electromagnetic Compatibility) Filter
Compatibility:- Suitable for use with Induction Motors and Permanent Magnet Motors
Software Tools:
– Drive Composer Pro for Configuration and Monitoring
– Drive Window Light for Basic Parameter Editing
Description
Introducing the ABB AC Drive ACS850-04-035A-5+J400: Unleash the Power of Precision Control
Enhance your industrial operations with the cutting-edge technology of the ABB AC Drive ACS850-04-035A-5+J400. Designed to provide unparalleled precision control and optimized performance, this AC Drive is the ultimate solution for a wide range of applications that demand reliable motor control and energy efficiency.
Key Features:
1. High Performance: The ACS850 series is engineered to deliver high-performance motor control, ensuring smooth and precise operation across various load conditions. With its advanced algorithms, it guarantees excellent speed and torque control, enabling your machinery to run efficiently and smoothly.
2. Powerful Output: With a power rating of 18.5KW, the ACS850-04-035A-5+J400 is capable of handling demanding industrial processes effortlessly. This robust power output makes it suitable for a diverse range of applications, from conveyor systems to pumps and fans.
3. Wide Voltage Range: Designed to accommodate different voltage requirements, this AC Drive operates seamlessly within a 415V voltage range. This versatility makes it adaptable to various power distribution systems.
4. Energy Efficiency: The ACS850 series is known for its energy-saving capabilities, helping you reduce operational costs and minimize environmental impact. The drive’s intelligent features optimize energy consumption while maintaining optimal performance levels.
5. User-Friendly Interface: The user interface of the ACS850-04-035A-5+J400 is intuitive and easy to navigate, allowing for effortless setup, configuration, and monitoring. The drive’s display provides real-time feedback on key operating parameters, enabling operators to make informed decisions.
6. Advanced Protection: Safety is a top priority, and the ACS850-04-035A-5+J400 incorporates a range of protective features to safeguard both the drive and the connected motor. Overcurrent, overvoltage, and temperature protection mechanisms ensure the longevity of your equipment.
7. Durable Build: ABB is known for its commitment to quality and durability. The ACS850 series is built to withstand the rigors of industrial environments, ensuring reliable performance even in challenging conditions.
8. Versatile Connectivity: The ACS850-04-035A-5+J400 offers multiple communication options, including Modbus and Ethernet, facilitating seamless integration into existing industrial networks. This connectivity enhances data exchange and remote monitoring capabilities.
Applications:
The ACS850-04-035A-5+J400 is versatile and can be applied in a variety of industrial sectors, including:
– Manufacturing: Improve the precision and efficiency of production lines.
– Material Handling: Enhance the performance of conveyor belts and automated systems.
– HVAC Systems: Optimize the operation of fans, pumps, and ventilation systems.
– Water Treatment: Ensure efficient water circulation and treatment processes.
Upgrade your industrial setup with the ABB AC Drive ACS850-04-035A-5+J400, and experience unmatched control, energy efficiency, and reliability. Unlock the potential for smoother operations, reduced downtime, and increased productivity. Trust in ABB’s legacy of innovation to take your industrial processes to new heights.
